IPC6222ER-X30P | 2MP 30x IR Network PTZ Dome Camera
৳ 42,000.00
• 1/2.8″ progressive scan CMOS
• Up to 1920 x 1080 resolution, 30fps
• 30x optical zoom (4.5~135mm)
• Ultra 265,H.265,ONVIF
• Smart IR, up to 150m IR distance
• All-weather design
• Alarm I/O,Audio I/O
• AC24V,DC24V,PoE,9~38W
• IP66,–40°C ~ +65°C
• (-P) PoE
Description
Uniview IPC6222ER-X30P 2MP 30x IR Network PTZ Dome Camera
Features:
Optics
* 30X Optical Zoom
* Accurate and fast focusing
* Smart IR, up to 150m (492ft) IR distance
* Optical glass window with higher light transmittance
* IR anti-reflection window to increase the infrared transmittance
* 120dB true WDR
Compression
* Ultra 265, H.265, H.264, MJPEG
* Embedded smart algorithm
* Triple streams
* Customized OSD
Network
* ONVIF Conformance
Structure
* Innovative snow-removing functionality
* More effective heat dissipation system
* Intelligent temperature control technology
* 6KV surge protection designed for network interface
IPC6222ER-X30P Specification:
| IPC6222ER-X30P | ||||||
| Camera | ||||||
| Sensor | 1/2.8″, 2.0 megapixel, progressive scan, CMOS | |||||
| Lens | 4.5 ~ 135mm, AF automatic focusing, and a motorized zoom lens | |||||
| Digital Zoom | 16 | |||||
| Optical Zoom | 30 | |||||
| DORI Distance | Lens (mm) | Detect (m) | Observe (m) | Recognize (m) | Identity (m) | |
| 4.5 | 69.8 | 27.9 | 14 | 7 | ||
| 135 | 2094.8 | 837.9 | 419 | 209.5 | ||
| The angle of View (H) | 71.7° ~ 2.4° | |||||
| The angle of View (V) | 43.4° ~ 1.3° | |||||
| The angle of View (O) | 88.2° ~ 2.8° | |||||
| Shutter | Auto/Manual; shutter time: 1 ~ 1/100000s | |||||
| Minimum Illumination | Colour: 0.001Lux (F1.5, AGC ON) 0Lux with IR | |||||
| Iris | Auto/Manual; F1.5 ~ F4.0 | |||||
| Day/Night | IR-cut filter with auto switch (ICR) | |||||
| Digital noise reduction | 2D/3D DNR | |||||
| S/N | >52dB | |||||
| IR Range | Up to 150m (492ft) | |||||
| Defog | Digital Defog | |||||
| WDR | 120dB | |||||
| Video | ||||||
| Video Compression | Ultra 265, H.265, H.264, MJPEG | |||||
| H.264 code profile | Baseline profile, Main Profile, High Profile | |||||
| Frame Rate | Main Stream: 2MP (1920*1080), Max 30fps; Sub Stream: 2MP (1920*1080), Max 30fps; Third Stream: D1 (720*576), Max 30fps | |||||
| HLC | Supported | |||||
| BLC | Supported | |||||
| EIS | Supported | |||||
| OSD | Up to 8 OSDs | |||||
| Privacy Mask | Up to 24 areas | |||||
| ROI | Up to 8 areas | |||||
| Motion Detection | Up to 4 areas | |||||
| Smart | ||||||
| Behavior Detection | Intrusion, cross line, motion detection, auto tracking | |||||
| Intrusion | Enter and loiter in a pre-defined virtual region | |||||
| cross line | Cross a pre-defined virtual line | |||||
| motion detection | Moving within a pre-defined virtual region | |||||
| auto tracking | Tracking the specified target | |||||
| Recognition | Face detection, Audio detection | |||||
| Intelligent Identification | Object Left, Object Moving | |||||
| Statistical Analysis | People counting | |||||
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication | |||||
| Audio | ||||||
| Audio Compression | G.711 | |||||
| Two-way audio | Supported | |||||
| Suppression | Supported | |||||
| Sampling Rate | 8KHZ | |||||
| Storage | ||||||
| Edge Storage | Micro SD, up to 256GB | |||||
| Network Storage | ANR | |||||
| Network | ||||||
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS | |||||
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | |||||
| Pan & Tilt | ||||||
| Pan Range | 360° (endless) | |||||
| Pan Speed | 0.1°/s ~ 240°/s | |||||
| Preset speed: 300°/s | ||||||
| Tilt Range | –15° ~ 90° (auto reverse) | |||||
| Tilt Speed | 0.1° ~ 160°/s | |||||
| Preset speed: 240°/s | ||||||
| Number of Presets | 1024 | |||||
| Patrol | Up to 16 patrols, up to 32 presets per patrol Note: The total number of patrols and patterns is 16. | |||||
| Home Position | Supported | |||||
| Interface | ||||||
| Audio I/O | Audio cable | |||||
| Input: impedance 35kΩ; amplitude 2V [p-p] | ||||||
| Output: impedance 600Ω; amplitude 2V [p-p] | ||||||
| Alarm I/O | 1/1 | |||||
| Network | 1RJ45 10M/100M Base-TX Ethernet | |||||
| General | ||||||
| Power | AC 24V±25%, DC 24V±25% | AC 24V±25%, DC 24V±25%, PoE (PSE Required) | ||||
| Power consumption: 9 ~ 42W | ||||||
| Dimensions (Ø x H) | Ø227 x 359.4mm (Ø8.9” x 14.2”) | |||||
| Weight | 5.28kg (11.6lb) | |||||
| Working Environment | -40°C ~ 65°C (-40°F ~ 149°F), Humidity: ≤95% RH (non-condensing) | |||||
| Ingress Protection | IP66 | |||||
